Automatic Feeding Six Head Forming Machine

The automatic feeding six head pill forming machine is currently the most advanced machine for pill forming products. Its hydraulic feeding device can automatically feed a 200 liter meat hopper truck, and its reasonable and simple design can accurately invert the materials in the standard meat hopper truck into the meat hopper bin; Centralized control by PLC, with touch screen for equipment debugging and control, and the ability to save usage formulas for convenient production use; The weight, size, and dispensing speed of the meatballs can be adjusted freely, with a speed of 1000-3000 pills per minute (1 ton to 1.5 tons per hour), resulting in high production efficiency; Mold replacement is simple and convenient, and the shaping and cutting of meatballs are controlled by a servo motor with an electronic cam. Compared with the mechanical cam used in traditional meatballs, it can better adapt to the use of various pulp materials by customers; Programming is flexible, multifunctional, and efficient, making it a new type of industrial automation equipment that integrates automation technology, computer technology, and communication technology.

If you are interested in our products, please contact us and we are always at your service.

请注意!由于技术革新、信息更新延迟、外语翻译偏差等原因导致产品信息存在误差，我方不承担任何法律责任，且对产品相关信息及本声明拥有最终解释权。
Please note that! Due to technological innovation, delayed information updates, foreign language translation deviations, and other reasons, there may be errors in product information. We do not assume any legal responsibility and have the final interpretation right for product related information and this statement.

product details

Equipment parameters

Equipment name	Automatic feeding six head forming machine
Equipment model	YR-M680
equipment power supply	380V/50HZ
equipment weight	about 240KG
equipment size	440 * 920 * 1600MM
equipment power	3.75KW
equipment production capacity	300-600 pieces/minute

Equipment introduction

The automatic six-head feeding molding machine is a cutting-edge piece of precision equipment that stands at the pinnacle of modern technological advancements in the domain of food processing machinery. This sophisticated machine is designed to handle the intricate demands of large-scale food production with remarkable efficiency and precision. It boasts a hydraulic feeding system that is capable of automatically supplying ingredients to a 200-liter meat hopper cart, ensuring a seamless and continuous flow of material throughout the production process.

The machine's design is both rational and straightforward, which allows for the precise transfer of materials from the standard meat hopper cart to the meat hopper box without any loss or contamination. This attention to detail in design not only maintains the integrity of the ingredients but also optimizes the overall performance of the machine.

Centralized control is achieved through a state-of-the-art PLC (Programmable Logic Controller) system, which is complemented by a user-friendly touch screen interface. This interface serves as the command center for equipment setup and control, enabling operators to input and save recipes for future use, thereby streamlining the production process and reducing the likelihood of human error.

One of the standout features of this machine is its ability to freely adjust the weight, size, and distribution speed of the meatballs. With a speed range that can vary from 1000 to 3000 pieces per minute (equivalent to 1 ton to 1.5 tons per hour), the machine demonstrates exceptional production efficiency, making it an ideal choice for high-volume food processing facilities.

The machine also facilitates simple and convenient mold changes, which is a significant advantage in the dynamic food industry where versatility is key. The shaping and cutting of meatballs are controlled by servo motors with electronic cams, a technological leap from the traditional mechanical cams used in meatball production. This advanced system can better accommodate the use of various meat materials, aligning with the diverse requirements of customers and ensuring that the final product meets the highest quality standards.

In essence, the automatic six-head feeding molding machine is not just a machine; it is a testament to the convergence of automation technology, computer technology, and communication technology. It represents a new era of industrial automation equipment that is programmable, versatile, and efficient, setting a new standard in the food processing industry.
